Product Details:

Place of Origin: CHINA
Brand Name: JSUS
Certification: CE
Model Number: 08J

Payment & Shipping Terms:

Minimum Order Quantity: 200PCS
Payment Terms: Western Union, L/C, T/T
Supply Ability: 100000PCS/M
Contact Now
Detailed Product Description

Specification
International Standard Wiegand 26 or 34 Interface or RS232 Interface
DC 5V-16V Working Voltage
Less than 80mA Static Current
5 to 10CM Reading Range
Support EM-ID Card or MIFARE 1 Card
0 C to 70C Ambient Temperature
10%-90% Ambient Humidity
International Standard Wiegand 26 or 34 Interface, Optional RS232 Interface
More than 100M Communication Distance
Any OEM or ODM is much welcomed.
72*22.5*123.5 or 55*22.5*123.5
Additional: Out Door use has additional US$1.00 per piece.

Installation
Using +type screw driver to loosen the screw between the panel and motherboard. And then embed the motherboard to the side wall with the plastic plug and screws.

Wire Connection
Red DC 5V-16V
Black GND
Blue D1
White D0
Brown BEEP
Green LED
Yellow Alarm
