vertical installation float level switch, ideal for water

Product Details:

Place of Origin:	CHINA
Brand Name:	JSUS
Certification:	CE&ROHS
Model Number:	FS-PH-2

Payment & Shipping Terms:

Minimum Order Quantity:	500PCS
Payment Terms:	Western Union, , L/C, T/T

Contact Now

Detailed Product Description

Type: 1A 2A
Max. Contact Rating: 10W 50W
Max. Switching Voltage: 100VDC 220VDC
Max. Switching Current: 0.5A 1.5A
Min. Breakdown Voltage: 200VDC 300VDC
Max. Carry Current: 1.0A 3.0A
Max. Initial Contact Resistance: (not include the wire) 150m Ω
Temperature Rating: -10 ~ +85 ℃
Float Ball Material: PP
Float Body Material: PP
Screw Nut Material: ABS
E-Ring Material: PP
